CX Racing FA20 Intercooler + Turbo Intake Piping Kit 2013 – 2021 Scion FR-S / Subaru BRZ / 86

Bolt On Fitment, Keeps Bumper and Lights. No Cut, No Relocation of Other Parts

APPLICATION:

-Chassis: FR-S, BRZ, GT86

-Motor: FA20

-Turbo: T3 Turbo with External Wastegate

NOTE:

This Intercooler Kit Is a Proprietary Design By CXRacing, Fits CXRacing’s FA20 Turbo Kit or Manifold for FRS/BRZ Chassis. However, For Other Manifold and Turbo that Are Positioned Differently, Modifications Are Required, or Does NOT Fit.

This Kit is for Intercooler Kit ONLY. Installed Pictures Shows other Parts of the Turbo Kit, Which Are NOT Included. We Offer Them Separately, Please Check website.

Intercooler + Brackets + Piping + Silicon Hose + Clamp + BOV + Air Filter

This is CXRacing’s Newest Products for the Application Stated Above. All Parts Are Developed from Ground Up in Our R&D Center in USA, Designed and Built for Improved Performance Gains, with Excellent Fitment and Easy Installation.

INTERCOOLER：
-Bar & Plate Intercooler
-Core Size: 22 x 7 x 2.5 inch
-Overall Size: 28 x7x 2.5 inch
-2.5″ Thick Core, 2.5″ Inlet & Outlet

PIPING:
-3″ Pipe Connects to Throttle Body, then Reduce to 2.5″ Intercooler Pipes

TURBO INTAKE:
-2.75″ Intake Pipe
-Air Fitler is Placed In the Front Center of the Chassis, Picks Up Cold Air

NOTES:
-Off Road or Track Use ONLY, NOT for Street Use
-Due to the Complexity of Swapping a Motor to Different Chassis, Please Make Sure You Understand the Application Stated Here is the Right Parts for Your Project

Click Below Picture to See Flowbench Test of the Intercooler:
