Description
| Specification | Value |
|---|---|
| Beadlock Style | High Lifter Universal |
| Bolt Hole Pattern | 4/137 |
| Load Capacity | 1200 lb |
| Mounting Position | Front/Rear |
| Size | 14×7 |
| Color/Finish | Matte / Black |
| Riding Style | ATV / UTV |
| Rim Diameter | 14″ |
| Rim Width | 7″ |
| Product Name | Wheel |
| Wheel Offset | 5+2 (+30 mm) |
| Units | Each |
| Base Color | Black |
| Material | Aluminum |
| Model | HL9 Beadlock |
| Type | Beadlock |
| Finish | Matte |
- Factory-installed valve stem
- 10 mm billet beadlock ring
- 5/16″ grade 8 hardware
- Classic 8-spoke design
- Bolt-in center cap
- Lifetime structural warranty
- The High Lifter Beadlock wheels include 4 starter bolts (silver) which need to be replaced once the standard bolts (gold) are attached.
- Impact wrenches are not recommended at any point during installation of the beadlock ring due to the possibility of over- or under-tightening the bolts.
- When mounting tires, using a 1/2″ socket, torque all bolts to 15 ft/lb.
