Description
Part #: man608005C-4
Vehicle Fitment:
7-Bolt 4G63
1996-2006 Evolution IV V VI VII VIII IX
1992.5-1999 Eclipse GST/GSX
1992.5-1998 Talon TSi
1992.5-1994 Laser RS
Manley Platinum Series Pistons:
• 2618 high strength material
• Lightweight design with offset wrist pin for quiet start-ups
• Pressure balance groove
• Will accommodate +1mm valve sizes
• Premium Steel top rings with Napier seconds and round wire locks included
• Recommended piston clearance .0035″ measured 1.100″ from the bottom of the oil ring
| Bore Size | 85.50mm |
|---|---|
| Crankshaft Stroke | 100.0mm |
| Rod Length | 150.0mm |
| Piston Type | Dish/Inverted Dome |
| Compression Height | 1.130 |
| Piston Material | 2618 Forged |
| Piston Ring Size | 1.2 1.2 2.8mm |
| Wrist Pin Size | 0.866 |
